Designradiator Rosy Max laag model 940x1282x98 3217W DRL
| Titel |
Designradiator Rosy Max laag model 940x1282x98 3217W DRL |
| Artikelnummer |
AV396175 |
| Fabrikantnummer |
0DN8750 |
| EAN code |
08719577549752 |
| Merk | DRL |
|---|
| Kleur | Wit |
|---|
| RAL-nummer | 9010 |
|---|
| Materiaal | Staal |
|---|
| Standaard kleur | ja |
|---|
| Vermogen elektrisch verwarmingselement | - W |
|---|
| | 1000x336x48 verticaal 397W DRL | 1200x1120x48 verticaal 1572W DRL | 2000x224x48 verticaal 504W DRL | 2300x1680x48 verticaal 4260W DRL | 672x1600x48 horizontaal 1224W DRL | 896x1900x48 horizontaal 1894W DRL | Max laag model 940x1282x98 3217W DRL | Tandem 1800x616x58 verticaal 1815W DRL |
|---|
| Hoogte | 1000 mm | 1200 mm | 2000 mm | 2300 mm | 672 mm | 896 mm | 940 mm | 1800 mm |
|---|
| Diepte | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 98 mm | 58 mm |
|---|
| Lengte | 336 mm | 1120 mm | 224 mm | 1680 mm | 1600 mm | 1900 mm | 1282 mm | 616 mm |
|---|
| Waterinhoud | 2.622 l | 10.06 l | 3.064 l | 25.92 l | 7.608 l | 11.728 l | 21.827 l | 14.19 l |
|---|
| Warmteafgifte EN 442 20°C - 75/65 | 397.8 W | 1572 W | 504 W | 4260 W | 1224 W | 1894 W | 3080 W | 1815 W |
|---|
| Diepte vanaf wand tot voorzijde | 84-84 mm | 84-84 mm | 84-84 mm | 84-84 mm | 97-110 mm | 97-110 mm | 98-98 mm | 84-84 mm |
|---|
